JMEV EV3 SPECIFICATIONS
● Dimension(mm): 3720*1640*1535
● Wheelbase(mm): 2390
● Front/rear wheelbase(mm)_ 1420/1420
● Mminimum turning radius(m): ≤5
● Ground clearance(mm): ≥110
● Curb Weight(kg): 1060
● GVW(kg): 1360
● Passenger: 4
● Voltage(V): 403
● Max.Speed (km/h): 110
● Range(km)(CLTC): 330
● 0-50kmh(s): ≤4.5
● E-Motor Type
● Permanent magnet synchronous (liquid cooled)"
● Maximum power (kW): 50
● Max.Torque(N·m): 125
● Single reduction gear
● Battery type: LFP
● Battery capacity (kW·h): 30,24
● Battery pack heating
● Fast charging+slow charging
● Front suspension
● McPherson independent suspension
● Rear suspension form
● Torsion beam semi independent suspension
● Steering, rack and pinion steering gear
● Electric power steering (with active return)
● Collapsible steering column
● Brake System
● Front Disc and Back Disc "
● ABS+EBD
● ESC
● WCBS
● EPB
● AUTOHOLD
● Hill Start Assist
● Comfortable parking
● Tire: 165/65 R15
● Aluminum alloy wheel hub
